Phoenix Model Westland Lysander 50-61CC Gas/EP ARF 126″ -1:4 3/4

Unique models built to exacting standards!
With quality wood construction, high-wing placement, and easy-to-control, docile flight characteristics, the 1:4 ¾ scale Westland Lysander is a plane you’ll love to own. It comes pre-covered and with much of the construction done so you can focus on what’s important—putting in the best gear and soaring! These aircraft were used by the British Army during WWII to drop off and retrieve agents from behind enemy lines in occupied France. Its exceptional agility and ability to use short landing strips or unprepared fields made it invaluable for the role.

This is the Radio Controlled, Gasoline or Electric Powered,
1:4 3/4 Scale Westland Lysander from Phoenix Model.
For Intermediate Flyers.

FEATURES
Construction: All wood, laser cut
Wing: Two-piece with struts
Covering: High quality self-adhesive
Cowl: Fiberglass, painted to match covering
Canopy: Clear plastic with painted-on frame lines, instrument panel
detail and pilot bust
Spinner: 3.75″ (95mm) diameter, constructed of plastic, black in
color
Landing Gear: Two-piece prebent aluminum, painted white, two
5.25″ (133mm) diameter main rubber wheels, 2″ (51mm) diameter
rubber tail wheel
Motor Mount: Plywood with aluminum standoffs
Engine Mount: Four rubber isolated aluminum standoffs
Fuel Tank: Approximately 24oz (750cc)

INCLUDES
Prebuilt Fuselage, Wing and Tail Sections, Landing Gear, Wheels,
Cockpit, Instrument Panel, Pilot and Instruction Manual

REQUIREMENTS
Radio: At least 8-channel
Servos: Eight standard size high torque, 2 aileron; 2 flap;
2 elevator; 2 rudder; 1 throttle (if using gasoline engine)
Receiver Batteries: Two 6.0V 2400-2600mAh NiMH
Building and field equipment
For Electric Power;
Motor: Rimfire 50cc recommended
Electronic Speed Control: 120A
Lipo Battery: 33.3-55.5V, 9-15S
Battery Charger: Compatible with selected battery
Propeller: 22x8E to 26x10E
For Gasoline Power:
Engine: 50- 61cc 2-stroke gasoline
Propeller: compatible with selected engine
Two stroke oil

SPECIFICATIONS
Wingspan: 126″ (3200mm)
Length: 74.8″ (1901mm)
Flying Weight: 23.1 – 26.4lbs (10.5 – 12kg)
Wing Area: 1464 sq in (94.56 sq dm)
Wing Loading: 36.04oz sq ft (110g/sq dm)
Wing Type: Naca airfoils
Servo mount: 0.83 x 1.6″ (21 x 42mm)
Center of Gravity (CG): 5.8″ (147mm) back from leading edge of the
wing measured at the fuselage
